SWVE-LR/SR: Winkel-Schwenkverschraubung, Einschraubgewinde BSPP mit Dichtkantenring, leichte + schwere Reihe
A | B | PN / Bar | L1 / mm | L2 / mm | L3 / mm | L4 / mm | L5 / mm | S1 | S2 | S3 | Material | Art.Nr. | Stutzen | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
G1/8 | 06 | 315 | 13 | 20 | 30 | 8 | 10 | 16 | 14 | 14 | 1.4571 | SWVE06L01 | XSWVE06L01 | |
G1/4 | 08 | 315 | 14 | 21 | 31 | 10 | 14 | 20 | 17 | 19 | 1.4571 | SWVE08L02 | XSWVE08L02 | |
G1/4 | 10 | 315 | 15 | 22 | 33 | 10 | 14 | 20 | 19 | 19 | 1.4571 | SWVE10L02 | XSWVE10L02 | |
G3/8 | 12 | 315 | 18 | 25 | 36 | 10 | 16 | 25 | 22 | 22 | 1.4571 | SWVE12L03 | XSWVE12L03 | |
G1/2 | 15 | 315 | 21 | 28 | 39 | 12 | 20 | 30 | 27 | 27 | 1.4571 | SWVE15L04 | XSWVE15L04 | |
G1/2 | 18 | 315 | 21 | 28,5 | 40,5 | 12 | 22 | 30 | 32 | 27 | 1.4571 | SWVE18L04 | XSWVE18L04 | |
G3/4 | 22 | 160 | 27 | 34,5 | 46,5 | 12 | 24 | 35 | 36 | 32 | 1.4571 | SWVE22L06 | XSWVE22L06 | |
G1 | 28 | 160 | 31 | 38,5 | 52,5 | 12 | 30 | 45 | 41 | 41 | 1.4571 | SWVE28L08 | XSWVE28L08 | |
G1 1/4 | 35 | 160 | 35 | 45,5 | 61,5 | 14 | 36 | 55 | 50 | 50 | 1.4571 | SWVE35L10 | XSWVE35L10 | |
G1 1/2 | 42 | 160 | 40 | 51 | 67 | 14 | 41 | 65 | 60 | 60 | 1.4571 | SWVE42L12 | XSWVE42L12 | |
G1/4 | 06 | 630 | 16 | 23 | 33 | 10 | 14 | 20 | 17 | 19 | 1.4571 | SWVE06S02 | XSWVE06S02 | |
G1/4 | 08 | 630 | 16 | 23 | 33 | 10 | 14 | 20 | 19 | 19 | 1.4571 | SWVE08S02 | XSWVE08S02 | |
G3/8 | 10 | 630 | 18 | 25,5 | 37,5 | 10 | 16 | 25 | 22 | 22 | 1.4571 | SWVE10S03 | XSWVE10S03 | |
G3/8 | 12 | 630 | 18 | 25,5 | 37,5 | 10 | 16 | 25 | 24 | 22 | 1.4571 | SWVE12S03 | XSWVE12S03 | |
G1/2 | 14 | 630 | 22 | 30 | 42 | 12 | 20 | 30 | 27 | 27 | 1.4571 | SWVE14S04 | XSWVE14S04 | |
G1/2 | 16 | 400 | 21 | 29,5 | 42,5 | 12 | 22 | 30 | 30 | 27 | 1.4571 | SWVE16S04 | XSWVE16S04 | |
G3/4 | 20 | 400 | 26 | 36,5 | 51,5 | 12 | 24 | 35 | 36 | 32 | 1.4571 | SWVE20S06 | XSWVE20S06 | |
G1 | 25 | 400 | 31 | 43 | 59 | 12 | 30 | 45 | 46 | 41 | 1.4571 | SWVE25S08 | XSWVE25S08 | |
G1 1/4 | 30 | 400 | 36 | 49,5 | 65,5 | 14 | 36 | 55 | 50 | 50 | 1.4571 | SWVE30S10 | XSWVE30S10 | |
G1 1/2 | 38 | 250 | 41 | 57 | 76 | 14 | 41 | 65 | 60 | 60 | 1.4571 | SWVE38S12 | XSWVE38S12 |
