T-L/S: T-Verschraubung, leichte + schwere Reihe
A | PN / Bar | L1 / mm | L2 / mm | L3 / mm | S1 | S2 | Material | Art.Nr. | Stutzen | |
---|---|---|---|---|---|---|---|---|---|---|
06 | 315 | 12 | 19 | 19 | 12 | 14 | 1.4571 | T06L | XT06L | |
08 | 315 | 14 | 21 | 31 | 12 | 17 | 1.4571 | T08L | XT08L | |
10 | 315 | 15 | 22 | 33 | 14 | 19 | 1.4571 | T10L | XT10L | |
12 | 315 | 17 | 24 | 35 | 17 | 22 | 1.4571 | T12L | XT12L | |
15 | 315 | 21 | 28 | 39 | 19 | 27 | 1.4571 | T15L | XT15L | |
18 | 315 | 23,5 | 31 | 43 | 24 | 32 | 1.4571 | T18L | XT18L | |
22 | 160 | 27,5 | 35 | 47 | 27 | 36 | 1.4571 | T22L | XT22L | |
28 | 160 | 30,5 | 38 | 52 | 36 | 41 | 1.4571 | T28L | XT28L | |
35 | 160 | 34,5 | 45 | 61 | 41 | 50 | 1.4571 | T35L | XT35L | |
42 | 160 | 40 | 51 | 67 | 50 | 60 | 1.4571 | T42L | XT42L | |
06 | 630 | 16 | 23 | 33 | 12 | 17 | 1.4571 | T06S | XT06S | |
08 | 630 | 17 | 24 | 34 | 14 | 19 | 1.4571 | T08S | XT08S | |
10 | 630 | 17,5 | 25 | 37 | 17 | 22 | 1.4571 | T10S | XT10S | |
12 | 630 | 21,5 | 29 | 41 | 17 | 24 | 1.4571 | T12S | XT12S | |
14 | 630 | 22 | 30 | 42 | 19 | 27 | 1.4571 | T14S | XT14S | |
16 | 400 | 24,5 | 33 | 46 | 24 | 30 | 1.4571 | T16S | XT16S | |
20 | 400 | 26,5 | 37 | 52 | 27 | 36 | 1.4571 | T20S | XT20S | |
25 | 400 | 30 | 42 | 58 | 36 | 46 | 1.4571 | T25S | XT25S | |
30 | 400 | 35,5 | 49 | 65 | 41 | 50 | 1.4571 | T30S | XT30S | |
38 | 250 | 41 | 57 | 76 | 50 | 60 | 1.4571 | T38S | XT38S |
