Fig. 112/S:

ADNPN / BarL1 / mmL2 / mmF / mmMaterialArt.Nr.PDF
6S4630-20°C / +400°C80115701.04601011206S5
8S5630-20°C / +400°C80115701.04601011208S5
10S7630-20°C / +400°C80115701.04601011210S5
12S8630-20°C / +400°C80115701.04601011212S5
14S10630-20°C / +400°C100135901.04601011214S5
16S12400-20°C / +400°C100135901.04601011216S5
20S13400-20°C / +400°C100135901.04601011220S5
25S17250-20°C / +400°C1301651001.04601011225S5
30S24160-20°C / +400°C1301701001.04601011230S5
38S28160-20°C / +400°C1602201501.04601011238S5
6S4630-20°C / +400°C80115701.41041011206S4
8S5630-20°C / +400°C80115701.41041011208S4
10S7630-20°C / +400°C80115701.41041011210S4
12S8630-20°C / +400°C80115701.41041011212S4
14S10630-20°C / +400°C100135901.41041011214S4
16S12400-20°C / +400°C100135901.41041011216S4
20S13400-20°C / +400°C100135901.41041011220S4
25S17250-20°C / +400°C1301651001.41041011225S4
30S24160-20°C / +400°C1301701001.41041011230S4
38S28160-20°C / +400°C1602201501.41041011238S4
6S4630-20°C / +250°C80115701.45711011206S3
8S5630-20°C / +250°C80115701.45711011208S3
10S7630-20°C / +250°C80115701.45711011210S3
12S8630-20°C / +250°C80115701.45711011212S3
14S10630-20°C / +250°C100135901.45711011214S3
16S12400-20°C / +250°C100135901.45711011216S3
20S13400-20°C / +250°C100135901.45711011220S3
25S17250-20°C / +250°C1301651001.45711011225S3
30S24160-20°C / +250°C1301701001.45711011230S3
38S28160-20°C / +250°C1602201501.45711011238S3
