Fig. 15:

DIN A PN / Bar L1 / mm L2 / mm F / mm S1 Material Art.Nr. PDF
DIN 16261 B G1/4 6 -10°C / +50°C 61 54 36 22 1.4571 10015023
DIN 16261 B G1/2 16 -10°C / +50°C 80 67 60 27 1.4571 10015043
DIN 16261 B G1/2 16 -10°C / +50°C 80 67 60 27 1.4571 E10015043
DIN 16261 B G1/4 16 -10°C / +50°C 61 43 62 22 Messing 10015021
DIN 16261 B G3/8 16 -10°C / +50°C 54 43 62 22 Messing 10015031
DIN 16261 B G1/2 25 -10°C / +50°C 78,5 62 62 27 Messing 10015041
