SFS:

A B / mm DN L1 / mm L2 / mm C / mm Material Art.Nr. PDF
1/2-31,8 12,8 12 81 45,7 9,5 1.4571 4760DN12
3/4-41,3 16 16 84 45,7 12,6 1.4571 4760DN16
3/4-41,3 19,1 20 93,6 47,8 14,8 1.4571 4760DN20
1-47,6 19,1 20 96,6 50,8 14,8 1.4571 4760DN20G08
1-47,6 25,9 25 103 48 20,0 1.4571 4760DN25
1 1/4-54,0 32,5 32 133,2 73,4 26,0 1.4571 4760DN32
1 1/2-63,5 38,9 40 140 72,5 31,0 1.4571 4760DN40
2-79,4 51,6 50 150,2 82,7 40,0 1.4571 4760DN50
