BES:

A B / mm DN L1 / mm L2 / mm C / mm Material Art.Nr. PDF
8S 6,7 6 63,5 33,5 3,9 1.4571 4600DN0608
10S 6,7 6 63,5 33,5 3,9 1.4571 4600DN0610
12S 6,7 6 63,5 33,5 3,9 1.4571 4600DN0612
12S 8 8 63,5 33,5 5,4 1.4571 4600DN0812
12S 9,6 10 66,8 33,5 6,5 1.4571 4600DN1012
14S 9,6 10 69,8 36,5 6,5 1.4571 4600DN1014
16S 9,6 10 70,8 37,5 6,5 1.4571 4600DN1016
16S 12,8 12 73,5 38,2 9,5 1.4571 4600DN1216
20S 16 16 82,5 44,2 12,6 1.4571 4600DN1620
20S 19,1 20 90,5 44,7 14,8 1.4571 4600DN2020
25S 19,1 20 94,5 48,7 14,8 1.4571 4600DN2025
30S 19,1 20 98,5 52,7 14,8 1.4571 4600DN2030
30S 25,9 25 108,5 53,5 20,0 1.4571 4600DN2530
38S 32,5 32 118,5 58,7 26,0 1.4571 4600DN3238
