EVW-L/S:

A PN / Bar L1 / mm L2 / mm L3 / mm L4 / mm S1 S2 Material Art.Nr. Stutzen PDF
06 315 12 19 29 26 12 14 1.4571 EVW06L  EVW06LO
08 315 14 21 31 27,5 12 17 1.4571 EVW08L  EVW08LO
10 315 15 22 33 29 14 19 1.4571 EVW10L  EVW10LO
12 315 17 24 35 29,5 17 22 1.4571 EVW12L  EVW12LO
15 315 21 28 39 32,5 19 27 1.4571 EVW15L  EVW15LO
18 315 23,5 31 43 35,5 24 32 1.4571 EVW18L  EVW18LO
22 160 27,5 35 47 38,5 27 36 1.4571 EVW22L  EVW22LO
28 160 30,5 38 52 42 36 41 1.4571 EVW28L  EVW28LO
35 160 34,5 45 61 51 41 50 1.4571 EVW35L  EVW35LO
42 160 40 51 67 60 50 60 1.4571 EVW42L  EVW42LO
06 630 16 23 33 27 12 17 1.4571 EVW06S  EVW06SO
08 630 17 24 34 27,5 14 19 1.4571 EVW08S  EVW08SO
10 630 17,5 25 37 31 17 22 1.4571 EVW10S  EVW10SO
12 630 21,5 29 41 31 17 24 1.4571 EVW12S  EVW12SO
14 630 22 30 42 35 19 27 1.4571 EVW14S  EVW14SO
16 400 24,5 33 46 37,5 24 30 1.4571 EVW16S  EVW16SO
20 400 26,5 37 52 44,5 27 36 1.4571 EVW20S  EVW20SO
25 400 30 42 58 50 36 46 1.4571 EVW25S  EVW25SO
30 400 35,5 49 65 55 41 50 1.4571 EVW30S  EVW30SO
38 250 41 57 76 66,5 50 60 1.4571 EVW38S  EVW38SO
